Mangusta 104 REV

Specs & performance

CONSTRUCTION

Hull: SINGLESKIN COMPOSITE
Superstructure: SANDWICH COMPOSITE

DIMENSIONS

Length Overall: 31.80 M / 104'3''
Beam: ~ 7.1 M / 23'3''
Max Draft: ~ 1.5 M / 4'11''
Displacement at full load: ~ 120 T / 264,560 LBS
Displacement at half load: ~ 110 T / 242,500 LBS
Gross Tonnage: < 200 GT

TANK CAPACITY

Fuel Capacity: ~ 10,500 L / 2,770 US GALS
Water capacity: ~ 1,600 L / 425 US GALS

PROPULSION

Main engines power: 2 x MTU 16V 2000 M96L 2600 HP @ 2450 RPM (1939 kW)
Transmission: 2 X WATERJETS KAMEWA S63-4
Stabilizers: ZERO SPEED AND UNDERWAY

PERFORMANCE

Max speed half load: ~ 35 KNOTS
Cruising Speed half load: ~ 25 KNOTS
Range at cruising speed: ~ 370 NM

ACCOMMODATION

Guests: UP TO 10 IN 4 CABINS
Crew: 4 IN 2 CABINS

DESIGNERS

Exteriors: LOBANOV DESIGN / OVERMARINE GROUP
Interiors: LOBANOV DESIGN / OVERMARINE
GROUP CUSTOM INTERIORS AVAILABLE

REQUEST BROCHURE

We are almost there. Fill out the form with your data and receive the brochure.

First name

Last name

Email*

Phone number

Country

I agree to receive newsletters from Overmarine Group as per Privacy policy I agree to receive newsletters from Overmarine Group as per Privacy Policy

I hereby grant permission to use my personal details in accordance to the relevant Italian legislation I hereby grant permission to use my personal details in accordance to the relevant Italian legislation*

SOFT AND SINOUS SHAPES

Rounded glass surface on the wall at the far end of the room, which – at the mere push of a button – can change from opaque to transparent, to increase visibility from the steering station located just behind it.
The glass circular shape elegantly matches that of the skylight letting natural light softly shine through from the flybridge above.
COMFORT & RELAX

Automotive inspired second Helm Station
30 sqm | 320 foot2 Fly Deck
UNFORGETTABLE ONBOARD LIFE EXPERIENCE

The aft cockpit door opens completely, connecting the salon to the exteriors to create a dining area where guests can indulge in pleasant convivial moments.
THE GARAGE

Hidden behind the stylish aft door, the garage can fit a tender up to 5 metres and a 3-seat jet-ski.

SOFT AND SINOUS SHAPES

Rounded glass surface on the wall at the far end of the room, which – at the mere push of a button – can change from opaque to transparent, to increase visibility from the steering station located just behind it.
The glass circular shape elegantly matches that of the skylight letting natural light softly shine through from the flybridge above.
COMFORT & RELAX

Automotive inspired second Helm Station
30 sqm | 320 foot2 Fly Deck
UNFORGETTABLE ONBOARD LIFE EXPERIENCE

The aft cockpit door opens completely, connecting the salon to the exteriors to create a dining area where guests can indulge in pleasant convivial moments.
THE GARAGE

Hidden behind the stylish aft door, the garage can fit a tender up to 5 metres and a 3-seat jet-ski.
